LED Moisture-Proof Batten Light with 1x T8 Tube 4000K 150cm

Item number: FW151


Available now!

The premium series LED moisture-proof batten lights combine durability and versatility. Featuring replaceable T8 LED tubes, they deliver neutral white light at 4000K, ideal for demanding environments. The robust polycarbonate housing, complemented by stainless steel clips and mounting brackets for wall or ceiling installation, ensures maximum durability and protection, certified to IP65 and IK10 standards. Installation is made simple with quick one-person mounting, push-in terminal connectors, and through-wiring. All necessary mounting materials are included.


Wattage: 22 Watt

LED Feuchtraum Wannenleuchte 150cm 1x Röhre mit Leuchtmittel 4000K


Basis Daten
Base Data

Artikelnummer
Articlenumber
FW151
Gehäusematerial
Housing material
PC+PC
Material der Clips
Material of the clips
Edelstahl
stainless steel
Material der Leuchtmittel
Material of the Lighting Source
Glas
Schutzglas
Protective glass
Nein
No
Anzahl der Leuchtmittel
Number of LIghting Sources
1
Austauschbare Leuchtmittel
Replaceable Lighting Source
Ja
Yes
IP-Schutzklasse
IP Protection Class
65
IK-Code
IK code
IK10
Schutzart

Durchgangsverdrahtet
Through-wireable
Ja
Yes
Maximale Schaltleistung in LED Betrieb in W
Switching capacity when used with LED Lamps in W
1200
Leitungskabel
Cable
5 x 1,5 mm²
Sockel
Socket
G13


Elektrische Daten
Electrical  Data

Betriebsspannung in V
Working voltage in V
220 - 240 AC
Betriebsfrequenz in Hz
Operating frequency in Hz
50/60
Bemessungsleistung in W
Rated wattage in W
22
Nennleistung in W
Nominal wattage in W
22
Betriebstemperatur in °C
Working temperature in °C
-20 ... +40
Energieeffiziensklasse
Energy efficency class
F
Energieverbrauch
Energy consumption
22 kWh/1000h
Netzleistungsfactor
Power factor
0,5


Photometrische Daten
Photometrical Data

Bemessungslichtstrom in lm
Rated Luminous Flux in lm
2200
Nennlichtstrom in lm
Nominal Luminous Flux in lm
2200
Bemessungslebensdauer in h
Rated lamp lifespan in h
20000
Nennlebensdauer in h
Nominal lamp lifespan in h
20000
Lichtstromerhalt nach 2000 Stunden in %
Lumen remains at end of lifespan
in %
96
Lichtstromerhalt nach Lebensdauerende in %
Lumen remains at the end of lifespan in %
70
Anzahl der Schaltzyklen
Number of switch cycles
100000
Lichtfarbe (Bezeichnung)
Color Temperature (description)
Neutralweiß
Neutral White
Farbtemperatur in K
Color Temperature in K
4000
Farbwiedergabeindex Ra
Color rendering index Ra
> 80
Farbconstistenzlevel
Level of Color Consistance
6
Aufwärmzeit (60%) in s
Warm-up time (60%) in s
< 0,5
Startzeit in s
Starting time in s
0,2
Dimmbar
Dimmable
Nein
No
Bemessungshalbswertswinkel in °
Rated Beam Angle in °
130


Abmessungen und Gewicht
Dimensions and Weight

Länge in mm
Length in mm
1560
Breite in mm
Width in mm
73
Höhe in mm
Heigth in mm
75
Nettogewicht in g
Net. Weight in g
1700


Bestellungen und Verpackungsinformation
Ordering and Packaging Information


Artikelnummer
Article number
EAN
Barcode
Stück
Pieces
Abmessungen (in mm)
Dimension (in mm)
Gewicht (in g)
Weight gross (in g)
Volumen (in dm³)
Volume (in dm³)
FW151 4251351805349 1 1580 x 75 x 75 1800 8,888
FW151 4251351805349 9 1600 x 245 x 240 16200 94,08
Artikelnummer
Article number
EAN
Barcode
Stück auf Palette
Pieces on pallet
FW151 4251351805349 135

Energielabel
